Product information:

Model: RA15N251
Type: paper cone type (direct radiation)
Use: Amplify
Shape: round
Composition: single paper cone
Diaphragm material: non-paper
Magnetic circuit form: internal magnetic type
Frequency characteristics: full frequency band (full range)
Rated power: 500 (W)
Rated impedance: 8 (Ω)
Frequency Response: 45Hz-5(kHz)
Sensitivity: 98 (dB/W)
Sex-to-noise ratio: 97 (dB)
Harmonic Distortion: 1 (TMD%)

Packing list:

Neodymium Magnetic Woofer*1

Neodymium Magnetic Woofer RA15N251: 15-Inch Full-Frequency 500W Speaker

Overview

The RA15N251 is a high-performance 15-inch neodymium magnetic woofer designed for full-range audio applications. With a 500W rated power capacity and a 75mm voice coil, this speaker delivers exceptional sound quality and efficiency, making it ideal for professional audio systems, live sound reinforcement, and high-fidelity home audio setups.

Key Features

1. High Power Handling

• Rated Power: 500W

• Peak Power: Not specified

• Impedance: 8Ω


The RA15N251 is engineered to handle substantial power, ensuring robust performance in demanding audio environments.

2. Full-Frequency Response

• Frequency Range: 45Hz – 5kHz

• Sensitivity: 98 dB/W

• Signal-to-Noise Ratio: 97 dB

• Total Harmonic Distortion (THD): 1%merryaudio888.en.made-in-china.com+10The Gadget Centre+10SJC Defensive Security+10


This wide frequency response allows the RA15N251 to reproduce a broad spectrum of sounds, from deep bass to midrange frequencies, making it suitable for full-range applications.

3. Advanced Design and Build

• Cone Material: Single paper cone

• Diaphragm Material: Non-paper

• Magnetic Circuit: Internal neodymium magnet

• Cooling System: 75mm voice coilmerryaudio888.en.made-in-china.com+9The Gadget Centre+9SJC Defensive Security+9Toutlehautparleur.combluearan.co.uk+6merryaudio888.en.made-in-china.com+6hengdaaudio.en.made-in-china.com+6


The use of a neodymium magnet contributes to a lightweight design without compromising on power or efficiency.

4. Applications

The RA15N251 is versatile and can be used in various audio setups, including:

• Professional Audio Systems: For concerts, events, and venues requiring high-quality sound reinforcement.

• Home Audio Systems: Enhancing the audio experience in home theater or high-fidelity setups.

• Custom Speaker Builds: Ideal for DIY enthusiasts looking to create bespoke audio solutions.
